Please see the new upgraded version of this machine, the XP3
Sold from 2019 to 2020.
There’s a new star in the sewing world. And it will help you shine. Presenting the Luminaire Innov-ís XP1. Adorned with revolutionary StitchVision Technology which, through an innovative projection of light, allows you to find perfection in every stitch. It’s an enlightened sewing, embroidery and quilting experience, powered by technology that’s light years ahead.
STITCH PRECISION WITH NEW STITCHVISION TECHNOLOGY
Introducing StitchVision Technology, a revolutionary new system for virtually perfect stitch positioning and more precise previews via an intelligent projection of light. Preview, audition and edit designs and stitches directly on your fabric.
65 SQUARE INCHES OF WORKSPACE
13.1" NEEDLE TO ARM SPAN
Experience the freedom and comfort of sewing on 65 square inches of included workspace, giving you the power to handle virtually any project with ease. A generous needle to arm distance of 13.1" is our largest ever, able to fully accommodate a rolled king-sized quilt.
LARGE 10 5/8" X 16" FRAME
Make your projects larger than life with the new large 10 5/8" X 16" frame, the largest that Brother currently offers. This extra-large frame has efficient rubber plates on both sides of the inner frame to hold fabric securely.
SPRING LEVER RELEASE
A new ergonomic Spring Lever Release enables easier, clamp free hooping. Simply place your fabric in the hoop and engage the lever.
LARGE 10.1" HD LCD TOUCH SCREEN DISPLAY
WITH CAPACITIVE TECHNOLOGY
The simple and intuitive 10.1" capacitive touch screen works like a tablet with familiar sliding, swiping, scrolling and pinch-to-zoom for viewing detailed steps, categories and designs. The user interface offers large, defined crystal-clear icons, and color navigation for easy viewing.
DISNEY IS IN OUR DNA
The Luminaire has the magic of 192 built-in Disney embroidery designs and 10 decorative Disney stitches. Additionally, access exclusive Disney and Disney.Pixar embroidery designs through the iBroidery.com Download Center.
ENHANCED INNOVEYE PLUS TECHNOLOGY
WIDER VIEW AND FASTER SCANNING IN HIGH RESOLUTION
It's like having a built-in camera and scanner! The ability to scan the entire embroidery area provides virtually endless creative options and helps ensure that all your projects are perfect.
MY DESIGN CENTER
Enhanced My Design Center integrates with our industry-first InnovEye Plus Technology to offer design capabilities at your fingertips, all without a PC. It's a great way to create custom personal works of art, and a really fun way to create embroidery!
- Scan it
- Convert it
- Embroider it
DUAL KING SPOOL THREAD STAND
Open the top cover to easily attach the included magnetic Dual King Spool Thread Stand. This space saving innovative stand helps ensure proper thread delivery as well as prevent broken stitches and uneven tension.
ONE ACTION NEEDLE PLATE
This thoughtfully designed feature allows for quick needle plate changes without the use of a screwdriver. No need to remove your extension table, embroidery unit or accessory tray - saving you time and effort for a seamless sewing experience.
BUILT-IN EMBROIDERY DESIGNS AND SEWING STITCHES
Let your imagination and creativity run wild with the extensive library of over 1,100 built-in embroidery designs, including Disney, Anna Aldmon, Zundt, ZenTangle and Pierre Joseph Redoute.
1,157
BUILT-IN EMBROIDERY DESIGNS
192
DISNEY & PIXAR CHARACTERS
670
BUILT-IN DECORATIVE STITCHES
10
DISNEY SEWING STITCHES
24
EMBROIDERY LETTERING FONTS
4
SEWING LETTERING FONTS
ENHANCED THREAD COLOR PALETTES
Our already generous thread color palette has been enhanced with the addition of Iris, Floriani, Simplicity, and Polyfast brands.
ACCESSORIES TO ENHANCE YOUR LUMINAIRE EXPERIENCE
Each accessory was carefully chosen to give you the best tools to complete your projects. Plus, Brother offers a range of optional accessories you can choose to enhance your experience even more.
FOUR HOOPS, INCLUDING BROTHER'S LARGEST HOOP TO DATE
Embroider monograms and other small designs with the 4" x 4" hoop. Use the 5" x 7" hoop for clothing embellishment or choose the 9.5" x 9.5" hoop for quilts and jacket backs. Accommodate your largest designs on the 10 5/8" x 16” hoop – our largest hoop to date.
14 DIFFERENT SEWING & EMBROIDERY FEET
Choose from a wide array of feet, including a free-motion quilting "C" foot, a free-motion echo quilting "E" foot and a 1/4" piecing foot for effortless quilting. Plus, the included industry-first camera detecting buttonhole foot will automatically detect which size button hole you need.
STRAIGHT STITCH NEEDLE PLATE
Easily and quickly switch your needle plate for sewing or quilting with a simple press of a lever – no screwdriver needed.
ACCESSORY CASE
Designed to fit within the arm of the large 13.1" needle-to-arm workspace, the accessory case will allow you to keep all your tools neatly organized and out of your way when not in use.
DUAL KING SPOOL THREAD STAND
Open the top cover to easily attach the included magnetic Dual King Spool Thread Stand. This space saving innovative spool thread stand helps ensure proper thread delivery as well as help prevent broken and distorted stitches and uneven tension.
ADJUSTABLE PRESSER FOOT KNEE LIFTER
Adjust the lever in three angles for ideal sewing position. Adjust the presser foot in four different heights.
Guaranteed to fit because it is a
part.
Basic Features
- Accessory Storage
- Yes
- Additional Specialty Feet Available
- Yes
- Adjustable Presser Foot Pressure
- Yes
- Adjustable Screen Brightness
- Yes
- Automatic Thread Cutter
- Yes
- Branded Series
- Disney
- Built-in Languages
- Yes
- Built-In Memory
- Yes
- Display Type
- LCD
- Feed Dog Points
- 7
- Included Accessory Feet
- 1/4 Inch Foot, Button Fitting Foot, Zipper Foot, Overcasting Foot, Blindstich Foot, Monogramming Foot, Zigzag Foot, Embroidery Foot, Free-Motion Quilting Foot
- LCD Display Size (W" x H")
- 5.3" x 8.5"
- Memory Card Reader
- Yes
- Needle Position Key (Up/Down)
- Yes
- Needle Threading System
- Automatic
- Presser Foot Leveling
- Yes
- Quick Set Bobbin
- Yes
- Realistic Preview
- Yes
- Screensaver
- Yes
- Specialty Feet Included
- Yes
- Start/Stop Button
- Yes
- Stitch Selector Type
- Touch Panel
- Thread Sensor
- Bobbin Sensor, Upper Thread Sensor
- Thread Sensor On/Off
- Yes
- UL/CSA Listed
- Yes
- Wide Table Included
- No
- Workspace Area
- 5" x 13.1"
Dimensions
- Unit Dimensions (W" x D" x H")
- 12.7" x 27.2" x 13.8"
- Unit Weight (lbs)
- 43.21
- Carton Width
- 24.606"
- Carton Height
- 28.74"
- Carton Length
- 35.236"
- Carton Weight
- 87.303 lbs
Embroidering
- Adjustable Design Icon Size Setting
- Yes
- Adjustable Embroidery Speed Settings
- Yes
- Appliqué Creator Function
- Yes
- Automatic Feed Thread Cutting
- Yes
- Built-In Border Function
- Yes
- Built-In Designs
- 1157
- Built-in Embroidery Designs featuring Disney/Pixar Characters
- 192
- Built-in Embroidery Lettering Alphabet Fonts
- 24
- Color Shuffling Function
- Yes
- Computer Connectivity
- Yes
- Curved Text on Screen Editing
- Yes
- Drag and Drop Editing
- Yes
- Embroidery Position Marker
- Yes
- Frame Designs - Shapes
- 10
- Frame Designs - Stiches
- 14
- Included Embroidery Hoops
- 4" x 4", 5" x 7"
- InnovEye Technology
- Yes
- Maximum Embroidery Speed (spm)
- 1050
- My Custom Design Feature
- Yes
- Onscreen Automatic Density Adjustment
- Yes
- On-Screen Editing
- Yes
- On-Screen Help
- Yes
- Pattern Rotating Increments
- 0.1 Degree, 1 Degree, 10 Degrees, 90 Degrees
- Print and Stitch Technology
- Yes
- Programmable Monochrome Embroidery
- Yes
- Resume Function
- Yes
- Sewing Decorative Stitches with Embroidery Arm Attached
- Yes
- Space Reduction among Embroidery Alphabets
- Yes
- Speed Adjustment
- Yes
- Thread Anchor
- Yes
- Thread Wiper
- Yes
- Trial Position/Layout Function
- Yes
Quilting
- Built-In Quilting Stitches
- Yes
- Built-in Sewing Lettering Fonts
- 3
- Drop-Feed
- Automatic
- Free Motion Quilting Foot
- Yes
- Included Quilting Feet
- Yes
Sewing
- Automatic Height Adjustment (AHA)
- Yes
- Back to Beginning Key
- Yes
- Built-In Stitch Selections (Stitches)
- 821
- Button Hole Styles
- 15
- Independent Bobbin Winding Motor
- Yes
- Knee Lifter
- Yes
- Maximum Sewing Speed (Stitches Per Minute)
- 1050
- Media Type USB
- Yes
- My Custom Stitch Feature
- Yes
- Pivot Function
- Yes
- Reinforcement/reverse Stitches
- Yes
- Sideways Sewing
- Yes
- Speed Control
- Yes
- Stitch Length (mm)
- 5
- Stitch Width (mm)
- 7
What's Included
- Cable
- Included
- Carton Contents‡
- 4 Embroidery Frame Sets, Straight Stitch Needle Plate, Large Accessory Case, Dual King Spool Thread Stand, Adjustable Presser Foot Knee Lever, Grid Sheet Set, ScanImation Scanning Frame, Embroidery Needle Plate Cover, Dual Purpose Stylus
Click here for the latest updates for this machine. <<<<<<<<
